    Honda Odyssey Service Manual > Blind Spot Monitor: Blind Spot Information System (BSI)   Radar Unit Inputs and Outputs
    1 2 3 4 5 6 Terminal side of female terminalsLEFT SIDE BSI RADAR UNIT 6P CONNECTOR Terminal number Wire color Terminal name Description Signal 1 LT GRN IG1 ECU RR(7.5A) Power supply for the BSI radar unit Vehicle in ON mode: Battery voltage Vehicle in OFF mode: About 0 V 2 RED DR BSI IND+ Drives th ...
